TR-D4251WDIR2 v3 3.6

Reservar una demostración Cómo comprar

Especificaciones técnicas

Audio:

audio in/out 1/1 / built-in microphone

WDR:

real WDR (120 dB)

Frame rate:

Electronic shutter speed:

1/2 ~ 1/12 500 s

IR range:

up to 20 m

Digital noise Reduction:

3D DNR

Corridor mode:

Yes

Resolución de cámaras (max):

2592x1920

Factor de forma:

Domo

Wi-Fi:

Sensor de imagen:

1/2.8" CMOS

Bitrate (Mb/sec):

up to 8Mbps

Fuente de alimentación:

PoE (802.3af) / 12V DC

Lente (mm):

3.6

Peso Neto:

0.31 / 0.40

Sensibilidad (Lux):

0.003Lux (F1.6)

Almacenamiento local:

MicroSD up to 512GB

Protección de ingreso:

IP66, IK10

IR:

Yes

Case material:

Metal

Protección contra rayos:

TVS 4000V

Power PoE:

2.9W

Dimensiones:

Ø102.20 x 56.38

El consumo de energía:

DC: 2.0W PoE: 2.9W

Temperatura de trabajo:

-40°C … +60°C

Modo Día/Noche:

Mechanic IR-filter

Field of view:

H79°±5°, V59°±5°

Class PoE :

802.3af/at

Video compression:

Н.265+ / Н.265 / H.264

Descripción

TRASSIR TR-D4251WDIR2 v3 (3.6 mm)

TRASSIR TR-D4251WDIR2 v3 3.6 5 MP (2592×1920) IP Camera is designed for outdoor use in all seasons. Its housing provides protection against dust and moisture (IP66), resists mechanical impacts (IK10), operates in extreme temperatures (-40 °C to +60 °C), includes lightning protection (TVS 4000), and features integrated IR illumination with a range of up to 20 m.

Functionality:

Face detection, motion detection, people detection, line crossing, area intrusion, loitering, vehicle detection, people counting
WDR 120 dB: Reduces the impact of high-contrast lighting on image quality
3D DNR: Spatial noise reduction
Corridor mode: Captures vertically oriented scenes
Defog: Enhances contrast to minimize the effects of fog and smoke
BLC: Backlight compensation
IR illumination: Up to 20 m
Video compression: H.265+, H.265, H.264
Main stream: 25–30 fps at 2592×1920 resolution

Main specifications:

1/2.8-inch CMOS sensor with 0.003 lux sensitivity
Day/night mode with ICR: blocks IR rays in sufficient light for optimized color reproduction; mechanically shifts in darkness to increase sensitivity
Bitrate: 8 Mbps
Fixed lens: 3.6 mm focal length, horizontal FOV 79° ±5°, vertical FOV 59° ±5°, aperture F/1.6
RJ-45 network port, built-in microphone
MicroSD slot supporting up to 512 GB
Power: DC 12 V, PoE
Maximum power consumption: 2.9 W
Dimensions: Ø102.20 × 56.38 mm
Weight: 310 g
